🔧 Block Settings

Overview​

The settings define the basic properties shared by blocks. You can enable all of them simultaneously. Below is an example containing all possible settings types:

Example
blocks:
  custom:all_settings_block:
    settings:
      hardness: 0.5
      resistance: 0.5
      is-randomly-ticking: true
      push-reaction: NORMAL
      map-color: 36
      burnable: false
      fire-spread-chance: 0
      burn-chance: 0
      item: custom:all_settings_item
      replaceable: false
      is-redstone-conductor: true
      is-suffocating: true
      is-view-blocking: true
      sounds:
        break: minecraft:block.deepslate.break
        step: minecraft:block.deepslate.step
        place: minecraft:block.deepslate.place
        hit: minecraft:block.deepslate.hit
        fall: minecraft:block.deepslate.fall
        land: minecraft:block.anvil.land
        destroy: minecraft:block.anvil.destroy
      require-correct-tools: true
      respect-tool-component: false
      correct-tools:
        - minecraft:wooden_pickaxe
      incorrect-tool-dig-speed: 0.3
      tags:
        - minecraft:mineable/pickaxe
      instrument: BASEDRUM
      fluid-state: water
      support-shape: minecraft:stone
      luminance: 15
      can-occlude: false
      block-light: 0
      propagate-skylight: false

Stable Settings​

hardness​

Determines how long it takes the player to destroy this block (Default: 2.0)

hardness: 0.5

resistance​

Determines the probability of the block surviving the explosion (Default: 2.0)

resistance: 0.5

is-randomly-ticking​

Determines whether the block state accepts random ticks, which is relevant for some block behaviors, such as leaves. (Default: false)

is-randomly-ticking: true

push-reaction​

Determines how the block reacts to piston pushes. Please note that some reactions may not work well with certain block types due to client visual sync issues. This problem will be fixed in future versions. (Default: NORMAL)

  • NORMAL Pistons can push and pull this block normally.
  • DESTROY Blocks pushed by pistons are destroyed instantly.
  • BLOCK Pistons cannot move this block.
  • IGNORE Seems to behave like PUSH_ONLY but can stick to sticky blocks
  • PUSH_ONLY Blocks can be pushed by pistons, but cannot be retracted. Do not stick to sticky blocks.
push-reaction: NORMAL

map-color​

Determines what color the block is displayed on the map. Available colors can be found on https://minecraft.wiki/w/Map_item_format (Default: 0)

map-color: 36

burnable​

Determines whether this block can be ignited by the environment (Default: false)

burnable: true

fire-spread-chance​

Determines how long the block can burn. A longer burn time means a greater chance of spreading fire to surrounding blocks. (Default: 0)

fire-spread-chance: 100  # 0-100

burn-chance​

Determines the probability of being ignited (Default: 0)

burn-chance: 30  # 0-100

item​

Determines the item that this block corresponds to. This is usually used to get blocks in creative mode with middle click. (Default: null)

item: default:xxx_block_item

replaceable​

Determines whether to replace the block at its original location when the player uses a block to interact with this block (Default: false)

replaceable: false

is-redstone-conductor​

Determines whether this block is a redstone signal conductor (Default: UNDEFINED)

is-redstone-conductor: true

is-suffocating​

Determines whether the player will take suffocation damage (Default: UNDEFINED)

is-suffocating: true

is-view-blocking​

Whether to block the line of sight. However, this option is useless for players, but it will affect some entity mechanisms on the server. (Default: UNDEFINED)

is-view-blocking: true

sounds​

Determines the sound of the block in various situations (Default: null)

  • fall When the player falls on this block
  • hit When the player digs this block
  • break When the player breaks this block
  • step When the player walks on this block
  • place When the player places this block
  • land When the block falls on ground (For falling blocks)
  • destroy When the block falls on ground and break (For falling blocks)
sounds:
  break: minecraft:block.deepslate.break
  step: minecraft:block.deepslate.step
  place: minecraft:block.deepslate.place
  hit: minecraft:block.deepslate.hit
  fall: minecraft:block.deepslate.fall
  land: minecraft:block.anvil.land
  destroy: minecraft:block.anvil.destroy
info

You can configure like this to precisely control the volume and pitch

sounds:
  break:
    id: minecraft:block.deepslate.break
    pitch: 0.5
    volume: 0.25~0.3 # ranged value is also supported
  step: minecraft:block.deepslate.step

require-correct-tools​

Determines if correct tool is required for the drops (Default: false)

require-correct-tools: false

respect-tool-component​

Decides if minecraft:tool component's correct_for_drops option should work as correct-tools below (Default: false)

respect-tool-component: false

correct-tools​

Determines the correct tool required to mine this block, otherwise no item will be dropped (Default: null)

correct-tools:
  - minecraft:wooden_pickaxe
  - minecraft:stone_pickaxe
  - minecraft:iron_pickaxe
  - minecraft:golden_pickaxe
  - minecraft:diamond_pickaxe
  - minecraft:netherite_pickaxe
tip

If correct-tools is set, require-correct-tools would be true

incorrect-tool-dig-speed​

Slows down the dig speed if the tool is incorrect (Default: 0.3)

incorrect-tool-dig-speed: 0.3 # 0~1

tags​

Tags determine the properties of many blocks. For example, using minecraft:mineable/axe will make your blocks mine faster with an axe. (Default: null) 🏷ī¸ Block Tags

tags:
  - minecraft:mineable/axe
  - minecraft:logs_that_burn
  - minecraft:logs
  - minecraft:completes_find_tree_tutorial

client-bound-tags​

This would only work for vanilla blocks

client-bound-tags:
  - minecraft:beacon_base_blocks

instrument​

Determines what instrument the note block will play when it is above this block. (Default: harp)

instrument: BASEDRUM

fluid-state ​

Decides the fluid state of this block state (Default: empty)

fluid-state: water

support-shape​

Determines the support shape provided by the block. By default, custom blocks will use the support-shape of their corresponding visual state. However, you can manually specify the support-shape of a vanilla block here instead.

support-shape: minecraft:stone

Unstable Settings​

caution

The remaining block settings are all related to the light system. CraftEngine has implemented partial light effects as much as possible without affecting server performance. Visual issues with the light system on the client side are normal and in most cases I can't fix them.

The block's occlusion of skylight is entirely determined by the client-side and cannot be fixed by sending packets from the server. Therefore, the block-light and can-occlude settings only affect block-emitted light, not skylight.

luminance​

Determines the light intensity of the block (Default: 0)

luminance: 15

can-occlude​

Determines whether this block can block light. This also determines whether the block can turn below block into another type. (For instance grass_block -> dirt) (Default: undefined)

can-occlude: false

occlude: true

occlude: false

occlude: false

occlude: true

block-light​

Determines how much light level is reduced after passing through this block (Default: undefined)

block-light: 0

block-light: 15

block-light: 7

block-light: 0

propagate-skylight​

Determines whether natural light can pass through this block.

propagate-skylight: true
